Inconel 713C Round Bar Vacuum Cast Superalloy AMS 5391 Turbine Blade Stock

Inconel 713C Round Bar — Vacuum Cast Nickel-Based Superalloy

Inconel 713C (UNS N07713, AMS 5391) is a vacuum melted, gamma-prime strengthened nickel-chromium superalloy supplied as cast round bar stock for the manufacture of turbine blades, nozzle guide vanes, integral wheels and other hot-section components. The grade combines high creep-rupture strength up to 982 °C (1800 °F) with excellent oxidation resistance in combustion gas environments, and it maintains useful ductility without the need for a protective coating in many service conditions.

Key Features

• Gamma-prime precipitation strengthened: the Al-Ti-Nb content forms a high volume fraction of gamma-prime phase, delivering outstanding high temperature strength and creep resistance in the 650–980 °C range.
• Oxidation and hot corrosion resistance: a chromium-rich, adherent oxide scale protects the surface in jet fuel combustion products, sulphidising and carburising atmospheres.
• Vacuum melting and casting: tight control of trace elements and gas content for consistent, inclusion-lean structure and repeatable mechanical properties.
• Machinable and weld repairable stock: round bar is supplied in the as-cast and aged condition for turning, milling, broaching and EDM into finished hot-section parts.
• Wide service window: suitable for continuous operation at component temperatures up to 982 °C with good thermal fatigue resistance.

Chemical Composition (wt. %, typical)

Typical Mechanical Properties (as-cast and aged, room temperature)

Applications

• Aero-engine and industrial gas turbine blades and nozzle guide vanes
• Integral turbine wheels and turbocharger rotors
• Hot-section structural parts for power generation and marine turbines
• Furnace fixtures, high temperature dies and wear-resistant tooling
• Chemical and petrochemical equipment exposed to oxidising high temperature service

Contact our technical sales team with your required diameter, length and quantity for a quotation.
