Monel K500 Forgings - High-Strength Nickel-Copper Alloy with Precipitation Hardening for Marine and Oilfield Applications

Monel K500 Forgings - High-Strength Nickel-Copper Alloy with Precipitation Hardening for Marine and Oilfield Applications
Monel K500 Forgings - High-Strength Nickel-Copper Alloy with Precipitation Hardening for Marine and Oilfield Applications

Large Image :  Monel K500 Forgings - High-Strength Nickel-Copper Alloy with Precipitation Hardening for Marine and Oilfield Applications

Product Details:
Place of Origin: China
Brand Name: DINGSCO
Certification: ISO 9001:2015,PED 2014/68/EU,API 6A,API-20B,TSG,NORSOK
Model Number: According to customers requirements
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: According to Customers' Requests
Delivery Time: (Sample Order) 7 days
Payment Terms: T/T
Supply Ability: Negotiable
Contact Now Chat Now

Monel K500 Forgings - High-Strength Nickel-Copper Alloy with Precipitation Hardening for Marine and Oilfield Applications

Description
Product Name: Monel K500 Forgings – High-Strength Nickel-Copper Alloy For Marine & Oilfield Applications Grade: Monel K500
UNS: N05500 Density: 8.44g/cm³
Melting Range: 1315 – 1350 °C Elastic Modulus: 179Gpa
Highlight:

Precipitation Hardening Monel K500 Forgings

,

Marine Applications Nickel-Copper Alloy Forgings

,

Oilfield Applications N05500 Forgings

Monel K500 Forgings – High-Strength Nickel-Copper Alloy for Marine & Oilfield Applications


Monel K500 forgings combine the excellent corrosion resistance of Monel 400 with greatly increased strength and hardness obtained through precipitation hardening. As a nickel-copper alloy strengthened by aluminum and titanium, Monel K500 maintains high performance in seawater, chemical processing, and sour gas environments.

Our forgings are produced with precise temperature control and heat treatment, ensuring superior fatigue resistance, tensile strength, and dimensional accuracy. These features make Monel K500 forgings ideal for industries where both mechanical durability and corrosion resistance are required.


Key Applications:

  • Oil & gas drilling equipment and pump shafts

  • Marine propeller shafts and fasteners

  • Chemical industry valves, pumps, and fittings

  • Aerospace components requiring high strength and corrosion resistance


Advantages:

  • Twice the strength of Monel 400 while retaining ductility

  • Excellent resistance to seawater, alkalis, and non-oxidizing acids

  • Non-magnetic properties at temperatures down to -135°C

  • Extended service life in harsh working environments


Chemical Composition:


Element Ni Cu C Mn Fe S Si Al Ti
Minimum(%) 63 27 - - - - - 2.3 0.35
Max(%) - 33 0.25 1.5 2.0 0.01 0.5 3.15 0.85



Thermal Properties:


Temperature Mean Linear Expansiona Thermal Conductivityb Specific Heatb Electrical Resistivityc
°F °C in/in/°F x 10-6 µm/m•°C Btu-in/h/ft2 /°F W/m•°C Btu/lb/°F J/kg•°C ohm-circ mil/ft µΩ•m
-320 -200 6.2 11.2 - - - - 330.8d 0.550
-250 -157 6.5 11.7 86 12.3 0.071 297.3 - -
-200 -130 6.8 12.2 92 13.1 0.077 322.4 - -
-100 -70 7.2 13.0 103 14.7 0.087 364.3 - -
70 21 - - 121 17.2 0.100 418.7 370 0.615
200 100 7.6 13.7 136 19.4 0.107 448.0 372 0.618
400 200 8.1 14.8 156 22.2 0.114 477.3 378 0.628
600 300 8.3 14.9 178 25.4 0.117 489.9 385 0.640
800 400 8.5 15.3 198 28.2 0.120 502.4 390 0.648
1000 500 8.7 15.7 220 31.4 0.125 523.4 393 0.653
1200 600 9.1 16.4 240 34.2 0.132 552.7 396 0.658
1400 700 9.3 16.7 262 37.3 0.141 590.3 400 0.665
1600 800 9.6 17.3 282 40.2 0.157 657.3 408 0.678
1800 900 - - 302e 43.1 0.186e 778.7 418 0.695

aBetween 70°F (21°C) and temperature shown. Age-hardened material.

bMaterial was in the annealed condition prior to test.

cElectrical resistivity is markedly influenced by thermal history because of the age- hardening characteristics of the alloy. The data shown represent values measured on decreasing temperature on material in an equivalent to annealed condition with a small amount of age hardening.

dResistivity of sample from this test tested at room temperature: 355.5 ohm/circ mil/ft.

eExtrapolated.
