Monel K-500 Round Bar ASTM B564 Forging Bar UNS N05500 W.Nr. 2.4375 Monel Alloy K-500

Monel K-500 Round Bar ASTM B564 Forging Bar UNS N05500 W.Nr. 2.4375 Monel Alloy K-500
Monel K-500 Round Bar ASTM B564 Forging Bar UNS N05500 W.Nr. 2.4375 Monel Alloy K-500 Monel K-500 Round Bar ASTM B564 Forging Bar UNS N05500 W.Nr. 2.4375 Monel Alloy K-500

Large Image :  Monel K-500 Round Bar ASTM B564 Forging Bar UNS N05500 W.Nr. 2.4375 Monel Alloy K-500

Product Details:
Place of Origin: China
Brand Name: DINGSCO
Certification: ISO 9001:2015,PED 2014/68/EU,API 6A,API-20B,TSG,NORSOK
Model Number: According to customers' requirements
Payment & Shipping Terms:
Minimum Order Quantity: Negotiable
Price: Negotiable
Packaging Details: According to customers' requests
Delivery Time: (Sample order) 7 days
Payment Terms: T/T
Supply Ability: Negotiable
Contact Now

Monel K-500 Round Bar ASTM B564 Forging Bar UNS N05500 W.Nr. 2.4375 Monel Alloy K-500

Description
Product Name: Monel K-500 Round Bar ASTM B564 Forging Bar UNS N05500 W.Nr. 2.4375 Monel Alloy K-500 Size Range: Ø8-Ø200,as Per Your Requirements
Application: Aerospace,Oil And Gas Industry,Chemical Processing Equipment,Nuclear Energy,Medical Devices Material: Nickel Alloy
Type: Round Bar Grade: UNS N05500 2.4375
Density: 8.44g/cm³ Surface Treatment: Bright
Standard: ASTM B564 Packaging: Standard Export Package
Highlight:

Monel Alloy K-500 Round Bar

,

Monel K-500 Round Bar

,

UNS N05500 Round Bar

Monel K-500 Round Bar ASTM B564 UNS N05500 W.Nr. 2.4375 Monel Alloy K-500



MONEL alloy K-500 (UNS N05500/ W.Nr. 2.4375) is a nickel-copper alloy which combines the excellent corrosion resistance of MONEL alloy 400 with the added advantages of greater strength and hardness. The increased properties are obtained by adding aluminum and titanium to the nickel-copper base, and by heating under controlled conditions so that submicroscopic particles of Ni3 (Ti, Al) are precipitated throughout the matrix. The thermal processing used to effect precipitation is commonly called age hardening or aging. The composition of the alloy is given as below.


       Typical applications for MONEL alloy K-500 products are chains and cables, fasteners and springs for marine service; pump and valve components for chemical processing; doctor blades and scrapers for pulp processing in paper production; oil well drill collars and instruments, pump shafts and impellers, non-magnetic housings, safety lifts and valves for oil and gas production; and sensors and other electronic components.

Grade UNS Density Tensile Strength
(MPa min)		 Yield Strength
(MPa min)		 Reduction of Area ,min (%) Elongation min (%) Hardness (HRC)
MONEL K-500 N05500 8.6 965MPa min 690MPa min 20 20% min HRC 27-35



Chemical Composition(%):


MONEL K-500 Ni Cu Fe C Mn
63.0min 27.0-33.0 2.0max 0.18max 1.5max
Al Ti S Si
2.3-3.15 0.35-0.85 0.015max 0.5max



More Grades:

Grade UNS DENSITY EN/DIN W.Nr CONDITION
Nickel 200 N02200 8.89 2.4066 Annealed
Nickel 201 N02201 8.89 2.4068 Annealed
MONEL 400 N04400 8.80 2.4360 Annealed
MONEL K-500 N05500 8.44 2.4375 Aged
INCOLOY 825 N08825 8.14 2.4858 Annealed
INCOLOY 925 N09925 8.08 - Aged
INCOLOY 926 N08926 8.1 1.4529 Sol.Annealed
INCOLOY A-286 S66286 7.94 - -
INCOLOY 800 N08800 7.94 1.4876 Annealed
INCOLOY 800H N08810 7.94 1.4958 Annealed
INCOLOY 800HT N08011 7.94 1.4959 Annealed
ALLOY 20 N08020 8.08 2.4660 Annealed
ALLOY 28 N08028 8.0 1.4563 Annealed
NIMONIC 80A N07080 8.19 2.4952 Aged
NIMONIC 901 N09901 8.14 2.4662 -
INCONEL 625 N06625 8.44 2.4856 Annealed
INCONEL 718 N07718 8.19 2.4668 Aged
INCONEL X-750 N07750 8.28 2.4669 Aged
INCONEL 600 N06600 8.47 2.4816 Annealed
INCONEL 601 N06601 8.11 2.4851 -
HASTELLOY C-276 N10276 8.87 2.4819 Annealed
HASTELLOY C-22 N06022 8.69 2.4602 Sol.Annealed
HASTELLOY C-4 N06455 8.64 2.4610 Sol.Annealed
HASTELLOY B-2 N10665 9.22 2.4617 Annealed
HASTELLOY B-3 N10675 9.22 2.4600 Annealed
HASTELLOY X N06002 8.22 2.4665 Aged
F44 S31254 8.0 1.4547 Annealed
F51 S31803 7.8 1.4462 Solution
F53 S32750 7.8 1.4410 Solution
F55 S32760 7.8 1.4501 Solution



Monel K-500 Round Bar ASTM B564 Forging Bar UNS N05500 W.Nr. 2.4375 Monel Alloy K-500 0

Monel K-500 Round Bar ASTM B564 Forging Bar UNS N05500 W.Nr. 2.4375 Monel Alloy K-500 1Monel K-500 Round Bar ASTM B564 Forging Bar UNS N05500 W.Nr. 2.4375 Monel Alloy K-500 2
